BenchK PS8 – Fischer Expansion Plugs with BenchK Wall Bar Screws 8 pcs (Series 1, 2, 5)

BenchK PS8 – Fischer Expansion Plugs with BenchK Wall Bar Screws 8 pcs (Series 1, 2, 5)

For various brick, concrete, and stone wall types.

Fischer DUOPOWER pins – depending on the base material, the gray element made of high-quality nylon automatically activates the optimal holding function (expanding, folding, rolling) for the best fixing.

The spreader wings of the red element provide expansion and additional protection of the gray element. Easily screwed in and tightened at the end. No risk of over-tightening the pin. The molded edge of the pin prevents it from falling into the hole.

Advantages

• Two different components (gray element and red element) allow for the highest load-bearing capacities.
• Good feeling when the pin is fully extended. You can feel the exact moment when the pin is properly fitted.
• A small collar on the outer edge of the plug prevents it from falling into the hole during assembly.
• Serrated shape on the side of the plug prevents it from turning during assembly.
• Increased anchoring depth makes the plug particularly suitable for fixing in hollow blocks, aerated concrete and plastered walls.

Applicable Wall Types

• Concrete
• Solid bricks
• Solid silicate bricks
• Aerated concrete
• Bricks with vertical perforation
• Perforated silicate bricks
• Plasterboard
• Gypsum plasterboards and gypsum fiber boards
• Light concrete hollow block blocks
• Hollow-core slabs of brick and concrete or the like
• Natural stone
• Particle boards
• Full gypsum boards

Assembly

• DUOPOWER pins are suitable for both pre-assembly and push-through assembly.
• The combination of two different materials of the dowel affects their various properties (expansion, folding and looping), which allows the use of additional substrates and obtaining the highest load capacity in them.
• The required screw length results from the length of the plug + thickness of the fastened element + 1x screw diameter.
• Wood screws, chipboard screws and hanger bolts can be used for the dowels.
• In the case of fastening to board materials, the unthreaded part of the screw must not be longer than the thickness of the fastened element.
• It is not recommended to use when the thickness of the wall is less than 4.7″.
